overhead bare AAAC conductors

  • Added time :
  • Specification :
  • Standard :
  • Voltage :
Description du produit
Paramètres

DESCRIPTION

 The condutor consists of Aluminum Magnesium-Silicon alloy wires stranded in successive layers in opposite direction and the outer layer is right hand direction Z . Natural grease may be applied between the layer of AAAC expect the outer layer.

STRANDARD

Construction as per ASTM B399 ,DIN 48201,BS EN 50182,IEC 61089,CSA C49

APPLICATION

AAAC bare conductors are used for primay and secondary overhead power transmission lines having long spans and high resistance to corrosion.

AAAC Technical Character Based on Standard ASTM B399

Norminal

Area (mm²)

Cross

section (mm²)

stranding and wires dia

(mm)

overall dia

(mm)

weight

(kg/km)

rated strength

(kN)

Max.D.C

Resistance

(Ω/km,20℃)

BOX 18.8 7/1.85 5.55 51.4 5.55 1.7480
ACACIA 23.8 7/2.08 6.24 64.9 7.02 1.3828
ALMOND 30.1 7/2.34 7.02 82.2 8.88 1.0926
CEDAR 35.5 7/2.54 7.62 96.8 10.46 0.9273
FIR 47.8 7/2.95 8.85 130.6 14.11 0.6875
PINE 71.6 7/3.61 10.8 195.6 21.14 0.4591
ASH 180.7 19/3.48 17.4 496.1 53.31 0.1830
UPAS 362.1 37/3.53 24.7 997.5 106.82 0.0917
REDWOOD 996.2 61/4.56 41.0 2753.2 293.88 0.0334
